Max Trading specializes in supplying Honda CG125 Motorcycle Brake Cables, providing reliable braking solutions for high-frequency urban commuting. The front brake bears approximately 70% of the braking load and is a core safety feature for riding. We select 1.8mm high-strength steel wire, combined with a low-friction sleeve design, to achieve linear transmission of braking force and safety redundancy in extreme environments. As a leading motorcycle parts manufacturer/supplier in China, Max Trading is committed to providing durable, stable, and ready-to-use front brake cables, reducing installation and usage risks.
When the rider gently squeezes the left brake lever, the high-strength steel wire immediately generates linear tension, accurately and efficiently transmitting the operating force to the front braking system.
For the drum front brake commonly used on the CG125, the brake cable drives the brake cam to rotate, pushing the brake shoes to expand and press against the inner wall of the brake drum, achieving smooth deceleration through friction.
When the brake lever is released, the return spring quickly engages, causing the brake cable to retract, the brake shoes to return to their original position, and the braking state to be released.
The high-quality front brake cable achieves linear control where "force is directly proportional to braking effect":
Gentle squeeze of the brake lever: Gentle deceleration (e.g., slow driving in traffic)
Strong squeeze of the brake lever: Powerful braking (e.g., emergency braking)
The Honda CG125 Motorcycle Brake Cable uses 1.8mm high-strength steel wire + low-friction sleeve, achieving a transmission efficiency of up to 95%, effectively avoiding the problems of traditional brake cables being ineffective with light pressure and locking up with heavy pressure.
For models like the CG125 with a forward center of gravity, linear braking prevents front wheel lock-up or skidding, reducing the risk of overturning.
Urban auxiliary roads are complex, and mud and water can easily cause brake cable jamming or breakage.
Our innovative multi-layer sealing structure effectively isolates mud and moisture; the high-strength tensile steel wire core ensures stable performance during frequent braking or with loads ≤50kg. Equipped with a Progressive Warning System: When the brake cable is slightly damaged, the brake lever resistance increases significantly before breaking completely, providing at least 200 kilometers of safe riding distance for replacement.
Materials and Craftsmanship
Dual-structure design: Stainless steel wire + nylon braided protection, offering 70% better rust resistance compared to traditional iron steel wires, resulting in a longer service life.
Durability Verification
Tested for 100,000 brake fatigue cycles, far exceeding the industry standard of 50,000 cycles, ensuring stable performance under high-intensity use.
Factory Pre-tension Calibration
The brake cable is pre-tensioned at the factory, enabling "plug-and-play" installation, significantly reducing installation costs and safety risks.
|
Honda CG125 motorcycle accelerator cable |
Parameters |
|
Wire diameter |
1.8mm(High carbon stainless steel) |
|
Diameter of casing |
5mm (thickened EPDM rubber+nylon weaving) |
|
Length |
120cm |
|
Joint specifications |
8mm round hole, 6mm flat shape |
Q1: Can the Honda CG125 Motorcycle Brake Cable withstand rainy or muddy conditions?
A: Yes. Max Trading's multi-layer sealing design effectively blocks mud, sand, and moisture, ensuring stable braking performance even in rainy or flooded conditions.
Q2: Is there a warning before the brake cable breaks?
A: Yes, it is equipped with a progressive warning system. When the brake cable is damaged, the brake lever resistance increases first, providing at least 200 kilometers of safe riding distance for replacement.
Q3: Is the installation complicated?
A: Max Trading brake cables are pre-tensioned at the factory and can be used immediately after installation without additional adjustments, saving time and costs.
Q4: What are the advantages compared to ordinary universal brake cables?
A: Better rust resistance and wear resistance; precise linear braking control; high fatigue resistance; convenient installation and compatibility; more comprehensive safety redundancy design for extreme conditions.
