As a professional 12V Motorcycle Horn Supplier, we utilize 65Mn steel diaphragms and all-copper terminals to ensure a powerful and penetrating sound field even under fluctuating 12V voltage.
Max Trading's 12V Motorcycle Horn is not just a sound-producing device, but also an active safety guarantee for riders.
Dual-Tone System: Our high-end models use a dual-tone (460±30Hz & 390±30Hz) composite unit, simulating a "BA-BA" stereo effect. Compared to single-tone products, its road recognition is improved by 40%.
120° Sectoral Diffusion: The snail-shaped horn utilizes a bionic spiral sound chamber to achieve 120° wide-angle diffusion, ensuring an effective warning area in noisy city streets.
Ultimate Performance: Through testing, our 12V Motorcycle Horn can achieve 200,000 continuous honks without sound quality degradation, ensuring clear and crisp sound in emergency situations.
Considering off-road riding and variable climates, we have comprehensively upgraded the structure of our 12V Motorcycle Horn:
Waterproof Drainage: Innovative side-wing drainage structure improves waterproofing by 80%. Even in heavy rain or mud splashes, it can quickly drain accumulated water and keep the sound chamber dry.
Temperature Tolerance: The product has passed wide-temperature testing from -40℃ to 90℃. Whether in high-altitude regions or tropical jungles, the diaphragm maintains a stable vibration frequency.
Vibration-Resistant Connection Technology: Elastic buffer connectors are used to fix the diaphragm and housing, effectively isolating high-frequency vibrations from the engine and preventing loose contacts that could cause no sound or abnormal noise.
| Feature | Value |
| Product Name | 12V Motorcycle Horn (High/Low Tone) |
| Working Voltage | DC $12\text{V} \pm 2\text{V}$ |
| Operating Current | $\le 1.5\text{A} - 4.0\text{A}$ |
| Sound Level (dB) | $105 - 118\text{dB}$ |
| Rated Power | $5\text{W} - 30\text{W}$ |
| Diaphragm Material | 65 Manganese Steel (Anti-Fatigue) |
| Terminal Material | 100% Pure Copper (High Conductivity) |
| Mounting Bolt | 8mm Universal Steel Bracket |
Our 12V Motorcycle Horn is designed to address the limited space at the front of modern motorcycles:
Space Optimization: The product diameter is controlled between 71.5-100mm, and the single unit weight is only 190-300g. The segmented structural design saves 30% of installation space.
Universal Compatibility: Standard 8mm mounting bracket, seamlessly compatible with mainstream brands such as Honda, Yamaha, and Suzuki.
Low Power Consumption: Compared to traditional horns, energy consumption is reduced by 30%, effectively reducing the load on the motorcycle battery and extending battery life.
Deep Industry Expertise: Founder Mr. Wang has been deeply involved in the industry for over ten years, adhering to the rigorous standard of "parts are the joints." We have selected over 100 cooperative factories from the core manufacturing regions of China, and strictly evaluate the contact melting point and moisture resistance of each 12V Motorcycle Horn.
Certification and Compliance: All horns hold ISO9001 and relevant international quality certifications. We use 65 manganese steel diaphragms and ABS+metal hybrid casings to ensure both impact strength and lightweight design.
Comprehensive After-Sales Service: We provide a 6-month official warranty (free replacement for non-human-caused failures).
A professional multi-lingual customer service team provides support within 24 hours.
Q1: Can this horn directly replace the original part?
A: Yes. The Max Trading 12V Motorcycle Horn uses a standard connector design, allowing for direct "plug-and-play replacement" on most models without cutting wires.
Q2: Will voltage fluctuations burn out the horn?
A: Our product has a built-in voltage stabilization protection module, which can operate stably within the range of 12V ± 2V, effectively avoiding coil damage caused by instantaneous voltage fluctuations.
Q3: Do you support OEM brand customization?
A: Absolutely. As a professional Motorcycle Electrical Parts Factory, we can customize your brand logo on the casing or packaging.
Low power operation design: The operating current is maintained in the range of 1.5-4A, with a power range of 5-30W. Compared with traditional horns, the energy consumption is cut down by 30%, minimizing the load on motorcycle batteries.
Intelligent circuit protection: High end products are equipped with reverse protection modules and voltage stabilization systems, which can operate stably in environments with 12V ± 2V voltage fluctuations, effectively avoiding irreversible damage to coils resulted by voltage fluctuations.
|
12v motorcycle horn |
Value |
|
Working Voltage |
DC 12V |
|
operating current |
≤1.5A-4A |
|
rated power |
5W-30W |
|
Terminal material |
iron |
Core material: The diaphragm is made of 65 manganese steel, which has excellent fatigue resistance and can effectively extend its service life; The terminal is made of pure copper material, which has strong oxidation resistance and ensures stable conductivity; The shell is made of a mixture of ABS and metal materials, balancing lightweight and high strength, with excellent impact resistance.
Certification Mark: It is recommended to prioritize products that have passed ISO 9001 quality certification. This certification means that the production process and quality control system meet the standards, which can avoid potential problems such as contact melting and poor moisture resistance in small brand products.
Warranty service: Provides a 6-month warranty period, during which if there is a non-human error, free replacement is supported; In case of transportation damage, corresponding compensation can be applied for, and the after-sales guarantee is complete and reliable.
